  • High Speed Carbide Drilling
  • Unmatched clamping – No Vibration
  • New and Improved Roller Measurement
  • 1800 RPM Spindle Specific Motors
  • Smart Spindle II


Beam Drill Line BDL-1250D

The BDL-1250/9D is a high speed evolution of an industry benchmark. With unmatched clamping power to accommodate ultra high speed carbide drilling the BDL boasts an impressive 1800 RPM spindle speed. Combine that with today's modern technologies that include micro-mist coolant, spindle specific motors, carbide part marking, Smart Spindle II technology and automatically adjusting roller measurement the BDL proves to be the industry's premier drill line.



The Industry's Premier Drill Line

The Peddinghaus BDL-1250/9D is the latest model in the BDL drill line series. Utilizing innovative technologies that include High Speed Carbide drilling, Increased Clamping Power, Spindle Specific Motors, Minimum Quantity Lubricant system, Central Greasing Unit, Smart Spindle Technology and the new and improved Roller measurement system the BDL-D has set the bar for drill systems the world over.
High Speed Carbide Drilling

At an impressive 1800 rotations per minute the BDL-D beam drill line brings high speed drilling to another level. With the ability to process beams, square tube, angle, and channel stock the BDL-D proves to be yet another versatile drill line in the Peddinghaus line-up.
Increased Material Clamping

In order to prevent dangerous and costly carbide tooling damage, the BDL-D drill line utilizes an improved clamping system that stabilizes material while drilling and even eliminates flex when processing thinner parts. These improvements include: a complete underside support system, 4 vertical axis clamps, increased drive roller surface, z-axis tower brakes, web clamp and a full linear rail braking system.
Patent Pending Smart Spindle II

The BDL-D beam drill line comes standard with the second generation of Smart Spindle technology which utilizes active linear feedback to lower process times and drill beams faster than ever before! This beam drill line monitors motor energy usage to determine the exact time of break-through and eliminates the inefficient drilling of air.
Cutting Edge Software

Peddinghaus' very own software designed specifically for our machines – Peddimat – is fully compatible with modern BIM software programs that can help boost your shops efficiency and save you valuable process time. Working with the industry's top software systems Peddinghaus engineers have designed Peddimat to be able to take parts directly from your modeling program to the Siemens control panel with ease.
Eco-Friendly MQL Coolant

The BDL-D beam line eliminates the need to clean materials before painting, welding, or doing any other processes. It utilizes an eco-friendly Minimum Quantity Lubrication system which eliminates the need to clean materials and remove large amounts of flood coolantPeddinghaus offers it's very own eco-friendly coolant – "Peddi-Cool" – designed for Peddinghaus equipment.
Part/Layout Marking

Signo-Script technology and spindle based layout marks come standard with the BDL-D beam drill line. Eliminate the need to do layout marks manually and increase efficiency, the Peddinghaus way!
Beam Drill Line Greasing System

Save time
greasing your machine with the BDL-D's beam line central greasing system. Simply fill the reservoir and let the machine do the rest!
Spindle Specific Motors

Using 25 HP (18.5 kW) Siemens Spindle Specific motors the BDL-D beam line delivers the exact spindle RPM desired no matter what the operating conditions are.



SPECIFICATION

BDL-1250D
Maximum Section Width 1250 mm
Minimum Section Width 75 mm
Maximum Section Height 610 mm
Minimum Length Piece Part 1650 mm
Maximum Section Weight 19867 Max kg
Spindle Horsepower 18.6 kW
Spindle Speed 145-1800 RPM
Number of Spindles 9
Tool Holder Komeet ABS 80
Drill Rapid Feed 6096 mm/min
Variable Feeds 25-630 mm/min
Maximum Hole Size 50 mm
