AFPS-623 / AFPS-643

회사명:
이름:
부서/직위:
E-메일:
전화번호:
문의사항
올해는 몇년도입니까?

Download
  • Process angle and flat stock up to 150 x 15 mm / 6 x 5/8 inch
  • Process Unlimited stock legnths
  • Automatically punch up to four hole diameters
  • Carbide part marking


(동영상이 끊길 경우, 잠시 일시정지를 눌러 주시기 바랍니다)

The Peddinghaus Anglemaster models AFPS 623 and AFPS 643 combine the technologies of hydraulic punching and shearing with automated carbide part marking into one efficient unit for automated processing of angle iron and flat stock.









The productive machine that pioneered the name "Anglemaster" with 6 x 6 x 1/2" angle, 6 x 1/2" flat stock efficiency. The single cut shear on the Peddinghaus Angle line minizies scrap and material handling.





Pinpoint Accuracy

Patented Entry and Exit Measuring wheel ensures accuracy for “end of material” measuring no matter your angle bar length. Safeguard your reputation by producing Accurate parts quicker than your competitors 100% of the time.

Integrated Carbide Marking

The integrated Signoscript carbide marking system provides legible part identification. Automated in the DSTV and DXF import process mark your parts quickly and easily.This automated marking process eliminates those handwritten headaches.



Single Cut Shear “Where speed is”
Full material utilization with no scrap loss. Optimized software helps to protect your investment.

What is the difference between a single cut and a double cut shear?

5-15% less scrap material!

A single cut shear produces no scrap when shearing your part. Double cut shears leave an average .5 inch scrap slug every time you produce an angle clip.

Rollerfeed Measuring

Minimize inventory and increase through put by loading material outside your shop. Roller feed technology provides more benefits over measuring carriage systems including: flexible material flow, reduced maintenance, no lost cycle time to clamp and unclamp, continual processing speed, and no problems associated with coped or cambered sections.



Unparalled Production

Two Men may produce 4160 Clips in one month working 40 hour weeks.
An Anglemaster will produce the same in less than 17 hours, with one operator.



One Pass Technology

Angles and flats are processed in one pass, reducing set-up time and delivering true punching performance.





SPECIFICATION

AFPS-643 AFCPS-623
Angle Maximum 150 x 150 x 15mm 150 x 150 x 15mm
Angle Minimum 40 x 40 x 4 mm 40 x 40 x 4 mm
Flat Maximum 150 x 12 mm 150 x 12mm
Flat Minimum 75 x 6 mm 75 x 6 mm
Punch Capacity 68 Metric Tons 68 Metric Tons
Punch Throat 133 mm 133 mm
Punch Stroke 44 mm 44 mm
Maximum Material Thickness 15 mm 15 mm
Maximum Hole Size 31.75 mm 31.75 mm
Shear Capacity 208 Metric Tons 208 Metric Tons
Tooling Style Single Cut Single Cut
