Portable Milling Machine

올해는 몇년도입니까?

Accurate "3 axis" machines for versatile portable milling.

(동영상이 끊길 경우, 잠시 일시정지를 눌러 주시기 바랍니다)

The D.L. Ricci Corp. "3 axis" Portable Milling Machines are our most versatile and accurate milling machine tool, capable of traveling and machining in all axis (XYZ). They are ideal for onsite machining large and small rectangular areas accurately. These Portable Mills can be clamped or bolted directly onto the part being machined or fabricated. Setup jigs and parallel-mounting fixtures can be used to position the portable mills for difficult work area conditions. Any machinist familiar with machining practices will find the Portable Milling Machines simple to setup and operate, even upside down.

These milling machine tools are designed for rugged onsite machining such as milling, drilling and boring applications on jobs that were previously thought to be impossible without extensive disassembly. The precision ground dovetails with adjustable gibs, to provide smooth, accurate travel in all axis.

When used as a facing mill, this milling machine tool will do a quick job of facing off pitted or misaligned surfaces, restoring the original condition of the part being machined. Servo power feeds are available for all axis, allowing the application of smooth and consistent power feed throughout the speed range, both in forward and reverse.
